[SINUS]제품 리뷰-Auditor
Auditor는 ISO 1996, TA-Laerm과 같은 국제 규격에 따른 소음 분석 소프트웨어 입니다. Auditor는 소음 발생 환경에서 분석용으로 주로 사용됩니다. 그리고 몇일 또는 몇 주 동안 발생하는 소음 측정 분석에 효과 적입니다.
소음 규격에 따라 효과적인 Noise rating level 값을 분석 해줍니다.
SAMURAI, siNoise, Tango-Utilities 소프웨어에서 저장한 값을 Auditor에서 Import가 가능합니다. 그리고 소음 분석 결과를 보고서로 출력 가능 합니다.
Tango, Soundbook, Swing, 그 외 SINUS measurement systems과 연동하여 사용 가능 합니다.
[SINUS] Auditor Features
- Display of level history data, spectra (octave, third-ctave and FFT), percentiles, interval values, FFT spectra from the computation of tonality and information content according to DIN 45681, and weather data.
- Import and comparison of measurement data from various measurement stations (different storage intervals)
- Computation of measurement results in user-defined periods
- Replay and analysis of recorded audio signals, allowing sections to be marked during the replay process
- Insertion and editing of markers to identify noise sources
- Clearly laid-out marker analysis table with automatic computation of values for marked sections (e.g. LAeq for the marked sections)
- Computations of the supplement for impulse content (KI) according to DIN 45641 (LAIeq – LAeq ) and DIN 45645-1 / TA-Laerm (LAFTeq – LAeq )
- Computations of the supplement for tonality and information content (KT) according to DIN 45681 and ISO 1996-2 (computation from FFT spectra)
- Computations for consideration of low-frequency noise according to DIN 45680
- Computation of LCeq - LAeq with display as level history and marker upon exceedance of either 20dB or 15dB
- Analysis of weather data
- Convenient tool for computation of the noise rating level Lr with user-specific intervention possibilities according to TA-Laerm and ISO 1996-2
- Chaining of analyses
- Document templates for computations and graphs
- Report and export function with predefined and freely-editable report
- Import of compressed measurement data from noise monitoring systems
- Project templates for recurrent analyses
[SINUS] Auditor 옵션
- Auditor
- Auditor_light : Auditor 기능에서 SAMURAI, siNoise 에서 import 기능 제외
- Auditor opt, Noisecam Video : SAMURAI video data import 가능
